quick info

The iX Series robotic total stations are a trimmed down, high- performance solution. You get the efficiency of a single-operator robotic system, the power of long range reflectorless measurements, and performance as a hybrid positioning solution.

Country Origin

Indian

Make / OEM

VERTEX

Model

Sokkia iX Series Robotic

Warranty

This Warranty covers the defects resulting from defective parts, materials or manufacturing, if such defects are revealed during the period of 12 months since the date of purchase.


All pictures shown are for illustration purpose only. actual product may vary due to product enhancement.

  • OVERVIEW

  • SPECIFICATIONS

  • FEATURES

  • VIDEO

  • DIMENSION

OVERVIEW

The iX Series robotic total stations are a trimmed down, high- performance solution. You get the efficiency of a single-operator robotic system, the power of long range reflectorless measurements, and performance as a hybrid positioning solution.

Ultra-powerful

UltraSonic technology is the driving force for the iX Series. The UltraSonic motors are the thinnest, lightest, and most powerful on the market – providing you with the smoothest and most accurate prism- tracking possible. It’s a difference you can see and hear immediately. With a rotation speed of 150° per-second, no matter how fast you move, or how many obstacles are in the way, you cannot outrun the iX.

Ultra-accurate

Our new UltraTrac technology gives you increased prism-tracking strength in all conditions. Advanced instrument algorithms deliver the confidence you need to move ahead. It’s not that you lose line-of-sight, it’s how fast you can reacquire and get back to work.

Ultra-slim and reliable

Featuring a remarkably slimmed down design, the compact system is a third smaller and lighter than previous robotic instruments, yet twice as fast. Without traditional gears or wearing parts, the UltraSonic motors are much more rugged and durable – lasting four times longer than previous total stations, and we back it with a five year warranty.

SPECIFICATIONS

Telescope
Resolving power 2.5″
Magnification 30x
Angle Measurement
iX-502 2″
iX-503 3″
iX-505 5″
iX-1001 1″
iX-1003 3″
iX-1005 5″
Tilt Angle Compensation
Compensation Liquid 2-axis tilt sensor
Range ±6’
Distance Measurement
Prism EDM Range
iX-500
iX-1000
4,000 m
6,000 m
Non-Prism Range
iX-500
iX-1000
600 m
800 m
Non-Prism Accuracy 2+2 ppm
Prism Accuracy
iX-500
iX-1000
2+2 ppm
1+2 ppm
Prism Accuracy
iX-500
iX-1000
Fine: 0.9 sec
Rapid: 0.6 sec
Tracking: 0.4 sec
