quick info

Soil Trimmer (Hand Operated) is used for trimming various diameter specimen for triaxial and unconfined compression tests.

Model

VSLIC-4158

  • OVERVIEW

  • SPECIFICATIONS

  • FEATURES

  • VIDEO

  • DIMENSION

OVERVIEW

The lower specimen grip is mounted on a disc that rotates freely. The soil sample is mounted on the lower specimen grip and the upper grip is firmly seated on top of the specimen. The vertical guide can be adjusted to control the depth of the cut. While trimming the lower disc is rotated by hand.

SPECIFICATIONS

Supplied complete with a wire saw. Trimming knife, mounted on a support, can be adjusted horizontally as well as vertically to permit trimming of the specimen to the exact size of the ring. A guide supplied prevents overcutting. Complete with 38mm, 50mm, 75mm, and 100mm dia specimen rings.

FEATURES

PRODUCT VIDEO

DIMENSION

Length (Inch)Width (Inch)Height (Inch)
